SENVAC SWH 300/550

This model is exclusively designed for welding fume extraction from welding, laser, plasma cutting process in industrial applications.

  • Suitable for on-torching welding fume extraction
  • High filtration efficiency
  • Easy to position in application areas as standalone system
  • Equipped with automatic pulse jet filter cleaning system
  • Technical Specifications
Model Units SWH 300 AC SWH 550 AC
Power KW/HP 3/4 5.5/7.5
Voltage V 400/3 400/3
Frequency Hz 50 50
Max. Airflow m3 /h 300 550
Max. Vacuum Pressure mm of H2 O 3000 3000
Filter Cartridge Nos 1 1
Filter Surface Area sq.m 10 10
Air Load on Filter m 3/m2 /h 30 55
Filter Type - Polyester Polyester
Filter Cleaning Method - Automatic Pulse Jet Cleaning System Automatic Pulse Jet Cleaning System
Filter Efficiency - 99.9% 99.9%
Collection Container Lt 70 70
Suction Inlet mm 80 80
Noise Level dbA 74 76
Protection Class IP 55 55
Dimensions (LxWxH) cm 180 x 66 x 140 180 x 66 x 140
Weight kg 124 146
